Oil GB-1476EC

Group	Filter Element Oil
Height, mm	203
Outer diameter, mm	120
Inner diameter, mm	55
Additionally	With gasket
Status	available

Attention! The provided filter parameters are for reference only and do not take into account tolerances

Print More information

Attention! This photo is for informational purposes only. Differences from the posted image are allowed, which do not affect the quality and functionality of the product

Buy on marketplaces:

Applicability

Attention! The manufacturer is not liable for any consequences resulting from the use of products outside the specified application range

Model (volume) Engine code KW power (H.P.) Model type	Year of manufacture
10.5 MC11 294(400) 10.5 MC11 294(400)	01/18	⇒
10.5 MC11 324(441) 10.5 MC11 324(441)	01/18	⇒

MAN TRUCK

Model (volume) Engine code KW power (H.P.) Model type	Year of manufacture
10.5 (xx.310) D 2066 228(310) 10.5 (xx.310) D 2066 228(310)	02/04	⇒	12/11
10.5 (xx.320) D 2066 235(320) 10.5 (xx.320) D 2066 235(320)	02/04	⇒	12/11
10.5 (xx.350) D 2066 257(350) 10.5 (xx.350) D 2066 257(350)	02/04	⇒	12/11
10.5 (xx.360) D 2066 265(360) 10.5 (xx.360) D 2066 265(360)	02/04	⇒	12/11
10.5 (xx.390) D 2066 287(390) 10.5 (xx.390) D 2066 287(390)	02/04	⇒	12/11
10.5 (xx.400) D 2066 294(400) 10.5 (xx.400) D 2066 294(400)	05/06	⇒	12/14
10.5 (xx.430) D 2066 316(430) 10.5 (xx.430) D 2066 316(430)	02/04	⇒	12/11
10.5 (xx.440) D 2066 324(441) 10.5 (xx.440) D 2066 324(441)	05/06	⇒	12/11

TGS (07-)

Model (volume) Engine code KW power (H.P.) Model type	Year of manufacture
10.5 (xx.320) D 2066 235(320) 10.5 (xx.320) D 2066 235(320)	10/07	⇒		i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.350) D 2066 257(350) 10.5 (xx.350) D 2066 257(350)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.360) D 2066 265(360) 10.5 (xx.360) D 2066 265(360)	10/07	⇒		i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.390) D 2066 287(390) 10.5 (xx.390) D 2066 287(390)	06/08	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.400) D 2066 294(400) 10.5 (xx.400) D 2066 294(400)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.430) D 2066 316(430) 10.5 (xx.430) D 2066 316(430)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.440) D 2066 324(440) 10.5 (xx.440) D 2066 324(440)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
12.4 (xx.480) D 2676 353(480) 12.4 (xx.480) D 2676 353(480)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
12.4 (xx.540) D 2676 397(540) 12.4 (xx.540) D 2676 397(540)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV

TGX (07-)

Model (volume) Engine code KW power (H.P.) Model type	Year of manufacture
10.5 (xx.360) D 2066 265(360) 10.5 (xx.360) D 2066 265(360)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.400) D 2066 294(400) 10.5 (xx.400) D 2066 294(400)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
10.5 (xx.440) D 2066 324(440) 10.5 (xx.440) D 2066 324(440)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
12.4 (xx.440) D 2676 324(440) 12.4 (xx.440) D 2676 324(440)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
12.4 (xx.480) D 2676 353(480) 12.4 (xx.480) D 2676 353(480)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
12.4 (xx.540) D 2676 397(540) 12.4 (xx.540) D 2676 397(540)	10/07	⇒	07/16	i Filtration system Hengst. Euro 4, Euro 5, EEV
16.2 (xx.680) D 2868 500(680) 16.2 (xx.680) D 2868 500(680)	10/07	⇒	06/14	i Quantity: 2 Piece

SITRAK

Model (volume) Engine code KW power (H.P.) Model type	Year of manufacture
10.5 MC11 294(400) 10.5 MC11 294(400)	12/17	⇒
10.5 MC11 324(441) 10.5 MC11 324(441)	12/17	⇒
12.4 MC13 353(480) 12.4 MC13 353(480)	12/17	⇒
12.4 MC13 397(540) 12.4 MC13 397(540)	12/17	⇒

Numbers OEM

CLAAS	0019910000
CLAAS	0019910001
DAF	1533857
INTERNATIONAL	2596171C91
LIEBHERR	11110427
MAN	51055040107
MAN	51055040108
MAN	51055040122
RENAULT	5021185682
SINOTRUK	200V055040108
SINOTRUK	200V055040122

Analogue

KOLBENSCHMIDT	4140OX
KOLBENSCHMIDT	50014140
MOTORDETAL	OFHU131253XE
CARVILLE RACING	CRLR131253X
AM POINT	OX425D
DIFA	DIFA5365E
AUGER	76636
BOSCH	F026407051
FEBI	45320
TOTACHI	TO1251
MECAFILTER	ELH4759
AMD	AMDFL374
EKOFIL	EKO02279
TOPCOVER	T12293001
KNECHT/MAHLE	OX425DECO
KNECHT/MAHLE	OX425D
FILTRON	OE6462
HENGST	E422HD86
SAMPA	02237201
KNORR-BREMSE	K117985N50
SAKURA	EO25040
MARSHALL	M9720011
U.F.I.	2504600
MILES	AFOE121
DONALDSON	P550820
FLEETGUARD	LF17056
SCT	SH4040P
GOODWILL	OG1061ECO
ZEKKERT	OF4364E
MANN	HU13125x
MANN	HU131253x
